Arrow Overview

Welcome to the Piper Arrow

The perfect combination of durability, reliability, comfort and technology – the Arrow is the ideal training platform. Students, instructors, and passengers alike will welcome the comfortable, 200 HP Arrow with the Garmin G500 TXi cockpit. Flight school owners will be delighted with the purchase and operating costs of this special trainer.

Find a Local Dealer Contact Fleet Sales

880 nm | 1,630 km Max Range

137 ktas | 254 km/h (75% power) Max Cruise Speed

1,600 ft | 487 m Takeoff Distance*

1,520 ft | 463 m Landing Distance*

*Over 50 ft Obstacle

  • Specifications
  • Avionics
  • Additional Equipment
  • Safety Features
  • Aircraft Design


  • Propeller
    McCauley 2-Blade
    Constant Speed
  • Fuel Capacity
    Usable: 72 US Gal | 273 Liters
  • Engine
    Lycoming IO-360-C1C6
    Horsepower: 200 hp
  • Dimensions
    Wingspan: 35 ft 5 in | 10.8 m
    Length: 24  ft 8 in | 7.5 m
    Height: 7 ft 10 in | 2.4 m



  • Standard Features
    • Single 10.6” Display
    • Garmin G500 TXi
    • Dual GTN650 NAV/COM/GPS (WAAS)
    • GTX335
    • GMA 350c Audio Panel
    • Standby Flight Instruments
  • Other Equipment
    • Tail Strobe Light
    • Wing Tip Recognition Lights
    • Overhead Air Distribution Blower Fan
    • Paint Scheme with Two Vinyl Trim Colors and Logo

Additional Equipment

Additional Equipment

  • GI 106A VOR/LOC/GS/GPS Indicator
  • Jeppesen ChartView
  • SVT – Garmin Synthetic Vision
  • TAWS-B
  • Flight Stream 510 with Connext
  • GDL 69A SXM Satellite Radio / Weather
  • GTX 345R Transponder with ADS-B IN and OUT
    • (Exchange for standard or GTX 335R transponder: ADS-B OUT only)
  • L3 WX-500 Stormscope
  • SKY-497 Skywatch Traffic Advisory System
  • BendixKing KR 87 ADF
  • BendixKing KN 63 DME
  • Electric Trim
  • Genesys System 55X Autopilot
  • United Kingdom Lighting Package
  • Nonstandard Paint Color – Top
  • Nonstandard Paint Color – Bottom
  • Nonstandard Approved Paint Scheme
  • AmSafe Seatbelts – Pilot and Co-Pilot Positions

Safety Features

Safety Features

As a personal commuter or as a high-performance transition trainer, this aircraft is a proven platform for safety and comfort. The Piper Arrow’s legacy only gets better with the Garmin G500® TXi Glass cockpit. Coupled with onboard weather, traffic, and terrain, situational awareness is exponentially increased.

  • Garmin Synthetic Vision Technology: SVT creates a visual topographic landscape from your system’s terrain-alerting database. The resulting 3-D display provides you with a lifelike depiction of ground and water features, airports, obstacles and traffic — all shown in relative proximity to your aircraft.
  • Skywatch™ Traffic Advisory System: monitors the airspace around your aircraft looking for aircraft that may pose a collision threat. Displayed information includes the relative range, bearing, and altitude of intruder aircraft.
  • GDL 69 SXM Weather: Sirius XM weather provides detailed NEXRAD data, current METAR reports, precipitation, lightning, winds-aloft, echo tops, TFRs, and more.  Information is provided using location-specific SiriusXM S-band geostationary satellites that provide seamless coverage at any altitude across the continental U.S..
  • L3 WX-500 Stormscop®: Stormscope uses a passive Mapping Sensor that detects electrical discharges associated with thunderstorms within a 200nm radius of the aircraft. This information is displayed and controlled via the G500. There is no transmitter and no harmful transmissions.  The sensor operates on the ground as well as in the air giving the pilot important planning information even before takeoff.
  • TAWS-B (Terrain Awareness and Warning System Class B.): Confidently navigate through airspace with high-resolution terrain mapping with alerts for; terrain clearance, premature and excessive rates of descent,  descent of aircraft to 500 feet above the terrain (voice call out of “Five Hundred”) and more.
Aircraft Design

Aircraft Design

Piper’s engineering and design teams lead the industry in designing aircraft for the owner-flown class of aircraft. Ergonomic controls, seats built for comfort, avionics placement and design, coupled with built-in durability and components chosen for reliability. Your students and instructors will appreciate the quality design and care in their Arrow.


Arrow Paint Scheme



The Cabin Above Class

The Arrow interior is ready for high flight hours while still providing maximum comfort and durability. The Arrow interior is specifically designed for the training environment. Creature comforts abound with high-end carpet and interior appointments, power plugs, lighting controls, and seat controls for each passenger.
